Not every steel structure project at a port is a brand-new building. A surprising number of RFQs come from existing facilities that need to replace aging steelwork, upgrade a conveyor gallery, or add a covered storage area next to an older shed. A new build starts from a clean site. A replacement project has to work around structures that are still operating, foundations that are already in place, and equipment that can’t be shut down for long.
When you’re putting up a shed next to an existing coal yard or replacing a section of conveyor steelwork, the constraints are mostly site-related. On an existing coal terminal, the available foundation positions and conveyor support points may already be fixed. Any replacement structure has to accommodate those conditions, along with the clearances required by operating equipment. The installation sequence also needs to be agreed with the port operator, particularly if conveyor access or nearby handling activities will be affected.
For projects with limited installation windows, a bolted space frame can reduce the amount of connection work required on site. Members and connection components can be prepared in advance, while erection and bolting are carried out according to the approved sequence. The actual time saving depends on access, lifting arrangements, the condition of the existing structure and how much of the facility must remain operational.
Several typical situations come up on working port facilities:
Adding a cover over an existing stockpile that’s currently open. This is different from building a shed from scratch, because the pile geometry, the stacker position and the reclaim path are already fixed. The structure has to fit around them, not the other way around.
Replacing a rusted conveyor gallery support. The old steelwork comes down in sections, the new bolted sections go up. The interface with the existing trestle and the conveyor alignment is the tricky part.
Extending an existing storage shed. You’re tying into one side of an older building, matching the elevation and the foundation layout. The connection detail at the interface takes more engineering than a free-standing structure.
Q: Can we extend an existing space frame shed with a new bolted section?
A: Usually yes, but the connection detail at the interface needs engineering review. The new section’s node positions and loading have to match the existing structure’s capacity. This is easier if the original structure was also a bolted ball-joint system.
Q: How can erection be scheduled while the port remains operational?
A: The installation sequence depends on which areas can be isolated and when equipment can be taken out of service. Work may be divided into stages during approved maintenance windows or other periods of restricted activity. Bolted connections can help reduce on-site connection work, but lifting access, temporary stability and inspection requirements still need to be included in the schedule.
Before choosing a structural system for a port upgrade, check the existing supports, equipment clearances, installation access and available work windows. These factors can affect both the design and the construction sequence.
For projects involving large-span storage buildings or space-frame replacements, LF-BJMB can review the preliminary requirements and assess whether a bolted space frame is suitable for the site conditions.For project references, see our solutions page.
